ANBO Grapple Rake 75 For Skid Steers and Tractors - Iron Elk

ANBO Grapple Rake 75 For Skid Steers and Tractors

by ANBO Manufacturing
$5,230.00 - $7,340.00
$5,670.00
$5,230.00 - $7,340.00
$5,670.00

Authorized Dealer for Loflin Fabrication

Ensuring quality backed by full manufacturer warranty & support.

FREE Ground Shipping: 7-10 business days

Shipping times may vary depending on seasonality and product availability. For a precise estimated ship date, please contact us at(301) 200-2113or emailsupport@landbossequipment.com.

Request a quote

The ANBO GR75 Grapple Rake is designed to meet the the demands of operators who require both strength and versatility. With thicker tines, larger hydraulic cylinders, and a robust clamp design, it’s perfect for clearing, digging, rock work, root removal, brush loading, and general debris handling. Built for machines up to 75 horsepower, this model bridges utility and heavy-duty duty.

FEATURES

  • Heavy AR400F Steel Construction
    Built with American AR400F steel, which is stronger, lighter, and more abrasion resistant than lower grade steels — delivering long life and reliability.
  • Thicker Tines for Added Strength
    Equipped with 5/8″ outer and 1/2″ inner AR400F tines, a step up from lighter models, to handle tougher loads and reduce bending under stress.
  • Large Jaw Opening (~48")
    The GR75 offers a jaw opening of about 48 inches, allowing it to clamp large, bulky debris with ease.
  • Robust Hydraulic Cylinders
    Depending on width, the unit uses 2.5" × 8" or 3" × 8" cylinders to provide the necessary clamping strength for heavier material.
  • Clamshell Dual Clamp Design
    The dual-grapple (clamshell) style ensures even pressure distribution across the load, improving grip and minimizing shifting during transport or dumping.
  • Greaseable Pivot Points & Secure Hose Routing
    All hinge points are greaseable for maintenance ease. Hydraulic hoses are routed through protective areas to reduce wear and risk of snagging.
  • Wide Width Options (59" to 94")
    Available in multiple widths to suit different machine sizes and job site needs
  • Built-In Warranty Protections
    Standard 2-year warranty on the grapple and a 3-year warranty on cylinders, giving greater confidence in durability and support.
  • Designed for Machines up to 75 HP
    Engineered as a top-tier utility/high-capacity grapple rake appropriate for mid-to-upper class machines.

SPECIFICATIONS

SKU Tine Spacing Width Weight Max HP Tine Size (Outer : Inner) Opening Cylinders
GR75 6" 59" 701 lb 75 hp 5/8" : 1/2" 48" 2.5" x 8"
GR75 6" 66" 757 lb 75 hp 5/8" : 1/2" 48" 2.5" x 8"
GR75 6" 72" 827 lb 75 hp 5/8" : 1/2" 48" 3" x 8"
GR75 6" 79" 878 lb 75 hp 5/8" : 1/2" 48" 3" x 8"
GR75 6" 85" 930 lb 75 hp 5/8" : 1/2" 48" 3" x 8"
GR75 6" 92" 986 lb 75 hp 5/8" : 1/2" 48" 3" x 8"
GR75 8" 60" 654 lb 75 hp 5/8" : 1/2" 48" 2.5" x 8"
GR75 8" 69" 714 lb 75 hp 5/8" : 1/2" 48" 2.5" x 8"
GR75 8" 78" 791 lb 75 hp 5/8" : 1/2" 48" 3" x 8"
GR75 8" 86" 826 lb 75 hp 5/8" : 1/2" 48" 3" x 8"
GR75 8" 94" 891 lb 75 hp 5/8" : 1/2" 48" 3" x 8"



SHIPPING & SUPPORT

This product ships directly from ANBO Manufacturing U.S. manufacturing facility. Standard lead time is 5–7 business days to ship.

Have questions or need help choosing the right size or accessories?
Contact us at sales@ironelkequipment.com or call (307) 832-5565 — our team is here to help.
